China wholesale Poly Pouch Printing Machine Factories – 6 Colour CI Flexo Printing Machine – Changhong Printing
China wholesale Poly Pouch Printing Machine Factories – 6 Colour CI Flexo Printing Machine – Changhong Printing
China wholesale Poly Pouch Printing Machine Factories – 6 Colour CI Flexo Printing Machine – Changhong Printing Detail:
The ci flexo printing machine sometimes becomes a common embossed cylinder flexo printing machine. Each printing unit is installed between two wall panels around a common embossing cylinder. The printed material is used for color printing around normal embossing rolls. Due to the direct drive of the gears, whether it is paper or film, even without special control devices, it can still register accurately and the printing process is stable.
The following is the whole workflow of printing paper material with Ci flexo printing machine.
|
TECHNICAL SPECIFICATIONS |
||||
| Model | CHCI6-600E | CHCI6-800E | CHCI6-1000E | CHCI6-1200E |
| Max. Web Width | 650mm | 850mm | 1050mm | 1250mm |
| Max. Printing Width | 550mm | 750mm | 950mm | 1150mm |
| Max. Machine Speed | 300m/min | |||
| Printing Speed | 250m/min | |||
| Max. Unwind/Rewind Dia. | φ800mm | |||
| Drive Type | Gear drive | |||
| Plate thickness | Photopolymer plate 1.7mm or 1.14mm (or to be specified) | |||
| Ink | Water base ink or solvent ink | |||
| Printing length (repeat) | 400mm-900mm | |||
| Range Of Substrates | LDPE; LLDPE; HDPE; BOPP, CPP, PET; Nylon, PAPER, NONWOVEN | |||
| Electrical supply | Voltage 380V. 50 HZ.3PH or to be specified | |||
1. The ceramic anilox roller is used to accurately control the amount of ink, so when printing large solid color blocks in flexographic printing, only about 1.2g of ink per square meter is required without affecting color saturation.
2. Due to the relationship between the flexographic printing structure, ink, and amount of ink, it does not require too much heat to completely dry the printed job.
3. In addition to the advantages of high overprinting accuracy and fast speed. It actually has a very big advantage when printing large-area color blocks (solid).
Product detail pictures:
Related Product Guide:
Our company puts emphasis on the management, the introduction of talented personnel, and the construction of staff building, trying hard to improve the quality and liability consciousness of staff members. Our company successfully attained IS9001 Certification and European CE Certification of China wholesale Poly Pouch Printing Machine Factories – 6 Colour CI Flexo Printing Machine – Changhong Printing , The product will supply to all over the world, such as: Poland, Cape Town, Canada, As a well educated, innovative and energetic staff,we are responsible for all elements of the research, design, manufacturing, sales and distribution. With studying and developing new techniques,we are not only following but also leading the fashion industry. We listen attentively to the feedback from our customers and provide instant communication. You will instantly feel our expertise and attentive service.
